2-13
Electronic control system
Water detection warning
If water is present in the fuel and the water detection switch in the fuel filter turns ON, the warning indi-
cator on the meter will be activated as shown in the table.
*. Displayed only when connected to YDIS
Water detection switch state Turning from ON to OFF Constant ON Remarks
Neutral
Indicator (symbol) Displayed for 30 sec. Always displayed —
Check Engine * Displayed for 30 sec. Always displayed —
Buzzer Sounds for 30 sec. Sounds constantly
Starts sounding
for 3 seconds af-
ter shifting into
neutral.
Trouble code 27 * Transmitted for 30 sec. Always transmitted —
In-gear
Indicator (symbol) Displayed for 30 sec. Always displayed —
Check Engine* Displayed for 30 sec. Always displayed —
Buzzer No sound No sound —
Trouble code 27 * Transmitted for 30 sec. Always transmitted —
