(3)
STEP feed
CD
Select
the
STEP
mode.
@
Select
movement
of
one
step
with
the MANUAL
PULSE
MULTI¬
PLY
selection
switch.
mm
System
0.001.
0.01.
0.1,
10.0,
100.0
mm/step
inch
System
0.0001,
0.001,
0.01.
0.1,
1.0.
10.0
in/step
(B)
Depress
the
JOG
key
of
the
axis
to
be
moved
and
the direction
in
which
it
is
to
be moved.
—
The
machine
moves
an
amount
equal
to
the
movement
per
step
selected
each time
the
key
is
depressed.
(4).
HANDLE
feed
*
.
The
following
operation
is
possible
if
equipped
with
a
manual handle.
(D
Select
the
HANDLE
mode.
(2)
Select
the
axis
to
be
moved
with
the
HANDLE
AXIS
switch.
@
Select
the
amount
of
movement
per
handle
graduation
with
the
MANUAL
PULSE
MULTIPLY
switch.
!
I
min
System
0.001
-0.01
-0.1
mm/scale
inch
System
0.0001-0.001-0.01
in/scale
Even
if
xlOOO
or
x]0000
is
selected,
it
becomes the
same
as
xioo.
0
Turn
the
manual handle
The
machine
moves
forward
or
backward
corresponding
to
the
direction
of
rotation
of
the
handle.
HANDLE
±
Foward
direction
Clockwise
(CW)
Q
Backward
direction
Counterclockwise
(CCW)
-
585
-
