7 - 12 TC75 User Guide
Establishing Ethernet Connection
1. Touch .
2. Touch .
3. Touch Ethernet.
4. Insert the device into a slot.
5. Slide the Ethernet switch to the ON position.
The icon appears in the Status bar.
6. Touch Eth0 to view Ethernet connection details.
Table 7-4 USB/Ethernet Module LED Data Rate Indicators
Data Rate (1) Yellow LED
(2) Green
LED
100 Mbps On/Blink On
10 Mbps On/Blink Off
NOTE Refer to the TC75 Integrator Guide for information on configuring the Ethernet settings.
