Zebra TC75 User Manual

Accessories 7 - 33
Figure 7-34 Cable Removed from TC75
2. Connect the USB connector of the cable to a host computer.
Charging the TC75
1. Connect the Snap-On USB Cable to the TC75.
2. Connect the power supply to the Snap-On USB Cable
Figure 7-35 Power Setup
3. Connect to the power supply to an AC outlet.
Disconnecting from TC75
1. Press down on the cable.

Zebra TC75 Specifications

General

Display Size	4.7 inches
Resolution	1280 x 720 pixels
Operating System	Android
Battery Capacity	4620 mAh
Cellular Connectivity	4G LTE
GPS	Yes
Humidity	5% to 95% non-condensing
Camera	8 MP rear camera
Wireless Connectivity	Wi-Fi 802.11 a/b/g/n
Ruggedness	MIL-STD-810G
Operating Temperature	-20° C to 50° C
Barcode Scanner	1D/2D imager
RAM	1 GB
Storage	8 GB
Expandable Storage	up to 32 GB microSD
Dimensions	6.3 x 3.3 x 1.1 inches
