7 - 26 TC75 User Guide
2.5 mm Audio Adapter
The 2.5 mm Audio Adapter snaps onto the back of the TC75 and removes easily when not in use. When attached
to the TC75, the Audio Adapter allows a user to connect a wired headset to the TC75.
Attaching the 2.5 mm Audio Adapter
1. Align the top mounting points on the Audio Adapter with the mounting slots on the TC75.
Figure 7-21 Audio Adapter Installation
2. Rotate the Audio Adapter down and press down until it snaps into position.
Figure 7-22 Rotate Audio Adapter onto TC75
