Accessories 7 - 29
3.5 mm Audio Adapter
The 3.5 mm Audio Adapter snaps onto the back of the TC75 and removes easily when not in use. When attached
to the TC75, the 3.55 mm Audio Adapter allows a user to connect a wired headset to the TC75.
Connecting a Headset to the 3.5 mm Audio Adapter
1. Connect the Quick Disconnect connect of the headset to the Quick Disconnect connector of the 3.5 mm Quick
Disconnect Adapter Cable.
Figure 7-27 Connect Headset to Adapter Cable
2. Connect the audio jack of the 3.5 mm Quick Disconnect Adapter Cable to the 3.5 mm Audio Adapter.
Figure 7-28 Connect Adapter Cable to Audio Adapter

Table of Contents

Other manuals for Zebra TC75

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra TC75 and is the answer not in the manual?

Zebra TC75 Specifications

General IconGeneral
Display Size4.7 inches
Resolution1280 x 720 pixels
Operating SystemAndroid
Battery Capacity4620 mAh
Cellular Connectivity4G LTE
GPSYes
Humidity5% to 95% non-condensing
Camera8 MP rear camera
Wireless ConnectivityWi-Fi 802.11 a/b/g/n
RuggednessMIL-STD-810G
Operating Temperature-20° C to 50° C
Barcode Scanner1D/2D imager
RAM1 GB
Storage8 GB
Expandable Storageup to 32 GB microSD
Dimensions6.3 x 3.3 x 1.1 inches
