Accessories 7 - 13
5-Slot Charge Only Cradle
The 5-Slot Charge Only Cradle:
•
Provides 5 VDC power for operating the TC75.
•
Simultaneously charges up to five TC75s and up to four TC75s and on 4-Slot Battery Charger using the
Battery Charger Adapter. See the TC75 Integrator Guide for information on installing the 4-Slot Battery
Charger onto the cradle.
•
Consists of a cradle base and cups that can be configured for various charging requirements.
Figure 7-9 5-Slot Charge Only Cradle
Charging the TC75
1. Insert the TC75 into a slot to begin charging.
1 Power LED – Lights green when power is applied to cradle.
