Accessories 7 - 35
Charging Cable Cup
This section describes how to use the Charging Cable Cup to charge the TC75.
Charging the TC75
1. Insert the TC75 into the cup of the Charging Cable Cup.
Figure 7-38 TC75 Charging
2. Ensure the TC75 is seated properly.
3. Slide the two yellow locking tabs up to lock the cable to the TC75.
Figure 7-39 Lock Cable Cup
4. Connect the power supply to the Charging Cable Cup and to a power source.
