Zebra TC75 User Manual

Getting Started 1 - 13
Figure 1-19 Remove Hand Strap Clip
5. Press the two battery latches in.
6. Lift the battery from the TC75.
7. Lift the access door.
Figure 1-20 Remove Access Door
8. Remove card from holder.
Figure 1-21 Remove Mini SIM/SAM Card
Figure 1-22 Remove Nano SIM Card

Zebra TC75 Specifications

General

Display Size	4.7 inches
Resolution	1280 x 720 pixels
Operating System	Android
Battery Capacity	4620 mAh
Cellular Connectivity	4G LTE
GPS	Yes
Humidity	5% to 95% non-condensing
Camera	8 MP rear camera
Wireless Connectivity	Wi-Fi 802.11 a/b/g/n
Ruggedness	MIL-STD-810G
Operating Temperature	-20° C to 50° C
Barcode Scanner	1D/2D imager
RAM	1 GB
Storage	8 GB
Expandable Storage	up to 32 GB microSD
Dimensions	6.3 x 3.3 x 1.1 inches
