Stratus OCT User Manual PN 2660021134133 A
Normative Database for Macula and RNFL Measurements
C-5
Figure C-3 illustrates how the age coefficient varies with A-scan number for a
representative scan line. The y-axis is the Age Regression Coefficient in micrometers per
year (μm/yr)
and the x-axis is the A-scan number (1 through 128).
Figure C-3 Age Regression Coefficient vs. A-scan Number
Figure C-4 illustrates the relationship between Total Macular Volume (mm3) and age, as
observed in the st
udy population.
Figure C-4 Total Macular Volume vs. Age in Study Population
Conclusion
The Macula Normative Database and RNFL Normative Database were based upon Stratus
OCT retinal scans collected from subjects whom, per protocol, were deemed representative
of a normal population. The Normative Databases establish reference values for specific
Stratus OCT retinal scans which the physician can use to compare individual patient
measurements to those acquired in a normal population.
