Stratus OCT User Manual PN 2660021134133 A
Configuration Guide
B-13
Note: To find the review station computer name:
• On systems running Windows 2000, right-click on the My Computer de
sktop icon and
select Properties. Then select Network Identification to find the computer name.
• On systems running Windows XP, select St
art, right-click My Computer and select
Properties. Then select Computer Name to view the computer name.
Note: You must use two backslashes before the computer name as shown in the
example.
Note: You must select the Reconnect at logon checkbox to allow the system to
reconnect to the shared drive each time Windows starts.
4. Click Finish to sa
ve your changes and close the Map Network Drive dialog.
On the Stratus OCT: Export Data to the Local Shared Folder
The new drive letter will now be available during the export process on the Stratus
instrument. In this example, the drive letter N: was mapped to the shared folder on the
review station. To export to the review station PC from the Stratus instrument, select the
mapped drive letter (N: in this case) as the export target. For more detail, refer to
Database Export on page 9-6.
On the Review Station PC: Import Data from the Local Shared Folder
To have access in Stratus Review Software to the data exported from the instrument, you
must complete the process by importing it from the local shared folder you created as
described above. In the example, this is the folder named Netshare on the Windows
desktop (Figure B-8). For details, see Import Data on page 9-10.
Note: For patients imported with the date of birth obscured, normative data will
not be presented in the analysis.
Stratus to Review Station Direct Network Connection
(Crossover Cable) Instructions
This section explains how to configure a direct network connection between the Stratus
OCT and a PC running Stratus Review Software. If you do not have a preexisting
networking infrastructure, this option provides an alternative. To do this, the sending and
receiving platforms must be connected by an unshielded RJ-45 crossover cable between
their respective ethernet ports. It is the user’s responsibility to acquire and install the
necessary crossover cable.
WARNING: When networking the Stratus OCT, use only network cables with
an unshielded RJ-45 connector. Use of a
shielded network cable in the Stratus
OCT could result in electrical shock to the patient and/or examiner.
Note: You should use a direct connection should only if no other networking
infrastructure exists, for the following reason: In this scenario, the Stratus
instrument and the review station PC will each be configured with a static IP address
