General Tips
The following general information and usage tips apply to all analysis protocols. Starting
with Retinal Thickness/Volume on page 6-13, this chapter provides a description and
specific usage tips for each protocol.
Analysis Protocols Are Correlated wit
h Scan Patterns
When selecting a protocol, it is
important to remember that the protocols are of two kinds:
image processing protocols and quantitative analysis protocols. Carl Zeiss Meditec
designed the image processing protocols for use with any scan. However, each quantitative
analysis protocol is designed for use with a certain scan type (line or circle) or scan pattern
made on a certain retinal location (macula or disc). Several of the scan protocols are
designed for use with a specific analysis protocol, or with a limited subset of analysis
protocols. An analysis protocol might work on an unintended scan type, but even if it does,
it may not provide meaningful output. The table below shows the scan protocols designed
for each quantitative analysis protocol.
Table of Correlations
Analysis Protocol Designed for Scan Group(s)
Retinal Thickness Any scan protocol except (F
ast) Optic Disc: 1 group on macula
Retinal Map Line, (F
ast) Macular Thickness Map: 1 group on macula
Retinal Thickness/Volume Line, (F
ast) Macular Thickness Map: 1 OS group and/or 1 OD group on
macula
Retinal Thickness/Volume
Tabular
Line, (F
ast) Macular Thickness Map: 1 OS and/or 1 OD group on macula
Retinal Thickness/Volume
Change
Line, (F
ast) Macular Thickness Map: 2 OS and/or 2 OD groups on
macula
RNFL Thickness Any scan protocol except (F
ast) Optic Disc: 1 group around disc
RNFL Thickness Average Circle, Proportional Circle, (F
ast) RNFL Thickness (3.4), RNFL Thickness
(2.27xdisc) or Nerve Head Circle: 1 OS and/or 1 OD of same radius
around disc
RNFL Thickness Map RNFL Map, Concentric 3 Rings: 1 OS and/or 1 OD group around disc
RNFL Thickness Change Circle, Proportional Circle, (F
ast) RNFL Thickness (3.4), RNFL Thickness
(2.27xdisc) or Nerve Head Circle: 2 OS and/or 2 OD of same radius
around disc
RNFL Thickness Serial Analysis Circle, Proportional Circle, (F
ast) RNFL Thickness (3.4), RNFL Thickness
(2.27xdisc) or Nerve Head Circle: Up to 4 OD and/or 4 OS groups of
same radius around disc.
GPA Advanced Serial Analysis RNFL Thickness (3.4) or Fast RNFL Thickness (3.4): Up to 8 OD and/or 8
OS groups of same radius around disc.
Optic Nerve Head (Fast) Optic Disc: 1 group on disc
Multi-Slice Report Any scan protocol
