Analysis Protocols
Stratus OCT User Manual PN 2660021134133 A
6-8
• The thinnest 5% of measurements fall in the yellow area or below
(1%  yellow < 5%, suspect below normal).
• The thinnest 1% of measurements fall in the red area. Measurements in red are
consider
ed below normal limits (red < 1%, below normal limits).

Note: Clinicians must exercise judgment in the interpretation of the macula
normative data. For any particular measurement, note that 2 out of 20 normal eyes
(10%) will fall either above or below green.
Edit Layers

Note: Edit Layers is an optional feature that may not be activated on all instruments.
If you do not have this feature and want to purchase it, contact Carl Zeiss Meditec.
In the U.S., call 1-877-486-7473; outside the U.S., contact your local Carl Zeiss
affiliate or distributor.
Version 5.0 and higher of Stratus OCT software includes the ability to
edit layers, that is, to
manually adjust the placement of the retinal layer boundaries, between which Stratus
measures the retina and RNFL thickness. The functionality described in this section is
available with all of the Analyses and Reports (see the list on page 6-2), except the
Optic Nerve Head analysis, which has a similar but distinct in
teractive capability.
Carl Zeiss Meditec designed the edit layer capability to give you direct control over
pla
cement of the retinal layer boundaries, enabling you to substitute your judgment in
place of the automated outcome of the Stratus thickness algorithms. This is especially
useful in cases where the retina has structural anomalies or pathology that may cause the
algorithms to incorrectly trace the actual boundaries.
Access the Layer Edit Dialog
When any applicable analysis is open, the Edit Layer butto
n becomes available, as well as
the Edit Layer option in the Data menu.
When available, click the Edit Layer button in the
toolbar or select Ed
it Layer from the Data menu (click Data > Edit Layer). The Layer Edit
Dialog opens.
