Interface description
LITECOM, Commissioning and maintenance instructions 17.0 | 04.2024 | en 20
Function
Brief description
(1)
Open app overview
Tap this button to access the app overview.
i
Note
For more information see Section App overview
(2)
Selecting effective range
Select the area containing the luminaires to be controlled.
i
Note
A default effective range can also be selected for the
start page. This effective range can be labelled with the
following icon:
For more information see Section User settings
(3)
Open the user settings
This button takes you to the user settings.
For more information see Section User settings
(4)
Function bar
Hold and drag the function bar vertically to change the intensity or
colour temperature.
· Intensity active: drag up to increase the intensity; drag down to
decrease the intensity
· TW (6) active: drag up to make the colour temperature warmer;
drag down to make the colour temperature cooler
(5)
Recall scene
All scenes for the selected effective range are listed in the function
bar. As soon as a scene is tapped, it is recalled. The background
image on the start page is the same image assigned to the selected
scene.
(6)
Switch between the settings for intensity and TW
Tap this button to change the colour temperature of the connected
TW luminaires by holding and dragging the function bar (4) vertically.
Tap this button again to change the intensity.
i
Note
If no TW luminaires are connected, the changes are
displayed on the screen but have no effect on the
connected luminaires.
(7)
Recall absence scene
As soon as the on/off key is tapped, the system alternates between
recalling the absence scene and recalling the Work scene.
It is also possible to recall the most recently active scene or a
permanently defined scene. This behaviour is defined in the Scenes
app.
Table 10: Pix functions
