ED-SENS mini
The ED-SENS mini is a multi-function sensor for presence and light detection.
Although the ED-SENS mini multi-function sensor is only one physical device, it appears twice in the system
image:
1 x for presence detection
For this reason, both a presence detector and a light sensor must be configured in the system image.
Presence detection
The presence or absence of moving persons is determined via the presence detection. This information is required
for presence linking, which is configured in the LITECOM CCD control device. If the LITECOM CCD fails, the
presence detector no longer works.
The following table provides a description of the parameters displayed:
Status which indicates whether the presence detector is currently detecting
the presence or absence of moving persons.
Table 41: Parameter – presence detection
Light detection
The light detection detects the available daylight in the room. This information is needed, inter alia, for the daylight
linking and for the conditional scene recall with the condition "twilight".
The following table provides a description of the parameters and functions which are displayed:
Reference value for calibrating the light sensor. Measure the reference
value with a luxmeter beneath the sensor and enter this value in the field.
LITECOM uses this reference value for daylight linking, among other things.
Procedure in which the reference value is stored which is subsequently
used for various functions (for daylight linking and the conditional scene
recall with the twilight condition, among other things).
Current sensor value (uncalibrated)
Illuminance (lx) which the uncalibrated light sensor is currently recording.
Current sensor value (calibrated)
Illuminance (lx) which the calibrated light sensor is currently recording.
Algorithm for daylight linking
Indicates the algorithm currently used for ambient light sensors.
Table 42: Parameters and functions – light detection
