Configuration
LITECOM, Commissioning and maintenance instructions 17.0 | 04.2024 | en 85
Presence detector
Presence detectors are used to determine whether moving people are present. This information is required for
presence linking, which is configured in the LITECOM CCD. If the LITECOM CCD control device fails, the
presence detector no longer works.
The following table provides a description of the parameters displayed:
Status which provides information about whether the presence detector is
currently detecting the presence or absence of moving persons.
Table 39: Parameter – Presence detector
Light sensor
Light sensors are sensors for recording the daylight in a room. The light sensors are subdivided into daylight
sensors and ambient light sensors.
· Daylight sensors: Sensors for recording the available daylight in the room (e.g.
ED-EYE).
· Ambient light sensors: Sensors that detect the reflected artificial light and daylight
in the room (e.g. ED-SENS).
Among other things, this sensor values is needed for daylight linking and the conditional scene recall with the
twilight condition.
The following table provides a description of the parameters displayed:
Illuminance (lx) which the light sensor is currently recording.
Table 40: Parameter – Light sensor
