ZyXEL Communications MES3500 Series User Manual

Chapter 16 Mirroring
MES3500 Series User’s Guide
142
16.3 RMirror-Source Screen
Use this screen to set the RMirror VLAN ID, configure the mirroring port and specify the traffic flow
to be copied when the Switch is the source device in remote port mirroring.
Click the RMirror-Source link in the Mirroring screen. The following screen opens.
Figure 73 Advanced Application > Mirroring > RMirror-Source
Apply Click Apply to save your changes to the Switch’s run-time memory. The Switch loses these
changes if it is turned off or loses power, so use the Save link on the top navigation panel to save
your changes to the non-volatile memory when you are done configuring.
Cancel Click Cancel to begin configuring this screen afresh.
Table 43 Advanced Application > Mirroring (continued)
LABEL DESCRIPTION
