ZyXEL Communications MES3500 Series User Manual

Chapter 21 Classifier
MES3500 Series User’s Guide
171
21.3 Viewing and Editing Classifier Configuration
To view a summary of the classifier configuration, scroll down to the summary table at the bottom
of the Classifier screen. To change the settings of a rule, click a number in the Index field.
Note: When two rules conflict with each other, a higher layer rule has priority over a lower
layer rule.
Figure 94 Advanced Application > Classifier: Summary Table
The following table describes the labels in this screen.
Socket
Number
Note: You must select either UDP or TCP in the IP Protocol field before you configure the socket
numbers.
Select Any to apply the rule to all TCP/UDP protocol port numbers.
Select Single and enter a TCP/UDP protocol port number.
Select Range and choose a pre-defined socket port range profile.
Destination
IP
Address
Select Prefix to enter a destination IP address and specify the address prefix by entering the
number of ones in the subnet mask. Otherwise, select Range and choose a predefined
destination IP address range profile.
Socket
Number
Note: You must select either UDP or TCP in the IP Protocol field before you configure the socket
numbers.
Select Any to apply the rule to all TCP/UDP protocol port numbers.
Select Single and enter a TCP/UDP protocol port number.
Select Range and choose a pre-defined socket port range profile.
Add Click Add to insert the entry in the summary table below and save your changes to the Switch’s
run-time memory. The Switch loses these changes if it is turned off or loses power, so use the
Save link on the top navigation panel to save your changes to the non-volatile memory when you
are done configuring.
Cancel Click Cancel to begin configuring this screen afresh.
Clear Click Clear to set the above fields back to the factory defaults.
Table 59 Advanced Application > Classifier (continued)
LABEL DESCRIPTION
Table 60 Classifier: Summary Table
LABEL DESCRIPTION
Rule
Usage
This field displays how many rules have been configured on the Switch.
Index This field displays the index number of the rule. Click an index number to edit the rule.
