Chapter 39 Maintenance
MES3500 Series User’s Guide
295
39.2 Load Factory Default
Follow the steps below to reset the Switch back to the factory defaults.
1 In the Maintenance screen, click the Click Here button next to Load Factory Default to clear all
Switch configuration information you configured and return to the factory defaults.
2 Click OK to reset all Switch configurations to the factory defaults.
Figure 188 Load Factory Default: Start
3 In the web configurator, click the Save button in the top of the screen to make the changes take
effect. If you want to access the Switch web configurator again, you may need to change the IP
address of your computer to be in the same subnet as that of the default Switch IP address
(192.168.1.1).
39.3 Save Configuration
Click Config 1 to save the current configuration settings permanently to Configuration 1 on the
Switch.
Click Config 2 to save the current configuration settings to Configuration 2 on the Switch.
Alternatively, click Save on the top right-hand corner in any screen to save the configuration
changes to the current configuration.
Note: Clicking the Apply or Add button does NOT save the changes permanently. All
unsaved changes are erased after you reboot the Switch.
39.4 Reboot System
Reboot System allows you to restart the Switch without physically turning the power off. It also
allows you to load configuration one (Config 1) or configuration two (Config 2) when you reboot.
You can restart the Switch immediately or set the Switch to restart at a specific time.
Click Management > Maintenance > Reboot System to view the screen as shown next.
