Chapter 6 Tutorials
MES3500 Series User’s Guide
53
11 Click the Save link in the upper right corner of the web configurator to save your configuration
permanently.
6.2.3 Configuring DHCPv4 Relay
Follow the steps below to enable DHCPv4 relay on the Switch and allow the Switch to add relay
agent information (such as the VLAN ID) to DHCP requests.
1 Click IP Application > DHCP > DHCPv4 and then the Global link to open the DHCP Relay
screen.
2 Select the Active check box.
3 Enter the DHCP server’s IP address (192.168.2.3 in this example) in the Remote DHCP Server 1
field.
4 Select a pre-defined Option 82 Profile that includes the system name, VLAN ID and port number
in the client DHCP requests (default2 in this example).
5 Click Apply to save your changes back to the run-time memory.
