Page #300 background imageLoading...
Page #300 background image
Chapter 39 Maintenance
MES3500 Series User’s Guide
300
39.9 FTP Command Line
This section shows some examples of uploading to or downloading files from the Switch using FTP
commands. First, understand the filename conventions.
39.9.1 Filename Conventions
The configuration file (also known as the romfile or ROM) contains the factory default settings in the
screens such as password, Switch setup, IP Setup, and so on. Once you have customized the
Switch’s settings, they can be saved back to your computer under a filename of your choosing.
ZyNOS (ZyXEL Network Operating System sometimes referred to as the “ras” file) is the system
firmware and has a “bin” filename extension.
You can store up to two images, or firmware files of the same device model, on the Switch. Only
one image is used at a time.
Run the boot image <1|2> command to specify which image is updated when firmware is loaded
using the web configurator and to specify which image is loaded when the Switch starts up.
You can also use FTP commands to upload firmware to any image.
The Switch supports dual firmware images, ras-0 and ras-1. You can switch from one to the other
by using the boot image <index> command, where <index> is 1 (ras-0) or 2 (ras-1). See the CLI
Reference Guide for more information about using commands. The system does not reboot after it
switches from one image to the other.
39.9.1.1 Example FTP Commands
ftp> put firmware.bin ras-0
This is a sample FTP session showing the transfer of the computer file "firmware.bin" to the Switch.
ftp> get config config.cfg
Mbuf Usage Click Download to see the Mbuf usage log report. The log includes Mbuf over
threshold information. This log report is stored in flash memory.
ROM File Click Download to see the Read Only Memory (ROM) log report. This report is
stored in flash memory.
Table 139 Management > Maintenance > Tech-Support
LABEL DESCRIPTION
Table 140 Filename Conventions
FILE TYPE
INTERNAL
NAME
EXTERNAL
NAME
DESCRIPTION
Configuration File config *.cfg This is the configuration filename on the Switch.
Uploading the config file replaces the specified
configuration file system, including your Switch
configurations, system-related data (including the
default password), the error log and the trace log.
Firmware ras-0
ras-1
*.bin This is the generic name for the ZyNOS firmware on the
Switch. ras-0 is image 1; ras-1 is image 2.
