ZyXEL Communications MES3500 Series User Manual

Chapter 40 Access Control
MES3500 Series User’s Guide
305
40.3.2 Supported MIBs
MIBs let administrators collect statistics and monitor status and performance.
The Switch supports the following MIBs:
• SNMP MIB II (RFC 1213)
• RFC 1157 SNMP v1
• RFC 1493 Bridge MIBs
• RFC 1643 Ethernet MIBs
• RFC 1155 SMI
• RFC 2674 SNMPv2, SNMPv2c
• RFC 1757 RMON
• SNMPv2, SNMPv2c or later version, compliant with RFC 2011 SNMPv2 MIB for IP, RFC 2012
SNMPv2 MIB for TCP, RFC 2013 SNMPv2 MIB for UDP
40.3.3 SNMP Traps
The Switch sends traps to an SNMP manager when an event occurs. The following tables outline the
SNMP traps by category.
An OID (Object ID) that begins with “1.3.6.1.4.1.890.1.5.8” is defined in private MIBs. Otherwise,
it is a standard MIB OID.
The OIDs beginning with “1.3.6.1.4.1.890.1.5.8.68” are specific to the MES3500-24 switch.
The OIDs beginning with “1.3.6.1.4.1.890.1.5.8.57” are specific to the MES3500-24F switch.
The OIDs beginning with “1.3.6.1.4.1.890.1.5.8.80” are specific to the MES3500-10 switch.
Table 143 SNMP System Traps
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
coldstart coldStart 1.3.6.1.6.3.1.1.5.1 This trap is sent when the Switch is turned
on.
warmstart warmStart 1.3.6.1.6.3.1.1.5.2 This trap is sent when the Switch restarts.
temperature TemperatureEventOn 1.3.6.1.4.1.890.1.5.8.68.27.2.1
1.3.6.1.4.1.890.1.5.8.57.27.2.1
1.3.6.1.4.1.890.1.5.8.80.27.2.1
This trap is sent when the temperature goes
above or below the normal operating range.
TemperatureEventClear 1.3.6.1.4.1.890.1.5.8.68.27.2.2
1.3.6.1.4.1.890.1.5.8.57.27.2.2
1.3.6.1.4.1.890.1.5.8.80.27.2.2
This trap is sent when the temperature
returns to the normal operating range.
