Page #34 background imageLoading...
Page #34 background image
Chapter 3 Hardware Overview
MES3500 Series User’s Guide
34
100 Mbps SFP Slots (MES3500-24F)
1 ~ 24 Amber On The port has a successfule connection.
Off No Ethernet device is connected to this port.
Blinking This port is receiving or transmitting data.
1000Base-T Ethernet Ports (in Dual Personality Interface)
LNK/ACT Green Blinking The system is transmitting/receiving to/from a 10 Mbps or a 1000 Mbps
Ethernet network.
On The link to a 10 Mbps or a 1000 Mbps Ethernet network is up.
Amber Blinking The system is transmitting/receiving to/from a 100 Mbps Ethernet
network.
On The link to a 100 Mbps Ethernet network is up.
Off The link to an Ethernet network is down.
FDX Amber On The Gigabit port is negotiating in full-duplex mode.
Off The Gigabit port is negotiating in half-duplex mode.
Table 4 LED Descriptions (continued)
LED COLOR STATUS DESCRIPTION
