Chapter 5 Initial Setup Example
MES3500 Series User’s Guide
46
1 Connect your computer to the Switch’s port which is not in VLAN 2.
2 Open your web browser and enter 192.168.1.1 (the default management IP address) in the address
bar to access the web configurator. See Section 4.2 on page 35 for more information.
3 Click Basic Setting > IP Setup in the
navigation panel.
4 Configure the related fields in the IP
Setup screen.
5 For the VLAN2 network, enter
192.168.2.1 as the IP address and
255.255.255.0 as the subnet mask.
6 In the VID field, enter the ID of the VLAN
group to which you want this
management IP address to belong. This is
the same as the VLAN ID you configure in
the Static VLAN screen.
7 Click Add to save your changes back to
the run-time memory. Settings in the
run-time memory are lost when the
Switch’s power is turned off.
