Chapter 6 Tutorials
MES3500 Series User’s Guide
63
3 Click Advanced Application > VLAN > Static VLAN.
4 In the Static VLAN screen, select ACTIVE, enter a descriptive name (VLAN 200 for example) in
the Name field and enter 200 in the VLAN Group ID field.
5 Select Fixed to configure ports 1, 2, 3 and 10 to be permanent members of this VLAN.
6 Clear the TX Tagging check box to set the Switch to remove VLAN tags before sending frames out
of these ports.
7 Click Add to save the settings to the run-time memory. Settings in the run-time memory are lost
when the Switch’s power is turned off.
