Aastra 470 System Manual

Installation
111
Aastra 470 ab R3.0
syd-0337/1.5 – R3.0 – 05.2013
4. 5. 6 Fitting IP Media modules
IP Media modules are fitted either to the Call Manager card or to PRI trunk cards. IP
Media modules are not stackable.
To fit an IP Media module to a Call Manager card, proceed as follows:
Warning
Be sure to observe the "Safety regulations", page 95.
1. Shut down the call manager via the control panel (see "On/Off key", page 240).
2. Unscrew the screw on the Call Manager card and remove the card by pulling the
fastening screw.
3. Remove the 2 fastening screws on the 2 premounted spacer sleeves on the IP
Media module.
4. Place the module in the slot and press it down evenly into the slot as far as the
stop.
5. Fit the module on to the call manager card from below using the 2 fastening
screws.
6. Carefully slide the Call Manager card into the shaft of slot 1 and gently press the
card as far as it goes into the connection on the backplane.
7. Secure the Call Manager card back into its slot with the screw.
8. Restart the call manager by pressing the On/Off button on the call manager
card.
Proceed accordingly to fit one or two IP Media modules to a PRI trunk card.
