Aastra 470 System Manual

Annex
284
Aastra 470 ab R3.0
syd-0337/1.5 – R3.0 – 05.2013
7. 3. 5 LAN switch
Tab. 130 LAN switch on CPU card CPU1
Tab. 131 LAN switch on the backplane
7. 3. 6 Digital and IP system phones
Tab. 132 Digital and IP system phones
Tab. 133 Dimensions and weights, digital and IP system phones
• 10Base-TX / 100Base-TX / 1Gb-TX switch
• Fully compliant with IEEE 802.3/802.3u
• Auto MDI-X, Autopolarity, Autonegotiation
• Flow control fully supported (half duplex: backpressure flow control, full duplex: IEEE 802.3x flow control)
• Embedded SRAM for packet storage
• 1024-entry look-up table, direct mapping mode
• QoS: 802.1p VLAN tag, DiffServ/TOS field in TCP/IP header, IP-based priority
• 100Base-TX
• Fully compliant with IEEE 802.3/802.3u
• Embedded SRAM for packet storage
• 1024-entry look-up table, direct mapping mode
• QoS: 802.1p VLAN tag, DiffServ/TOS field in TCP/IP header, IP-based priority
Aastra 5360/5360ip, Aastra 5361/5361ip, Aastra 5370/5370ip,
Aastra 5380/5380ip, Office 10, Office 25, Office 35, Office 45/45pro
Ambient temperature in opera-
tion
0 °C to 40 °C
Relative humidity in operation 30 % to 80 %
Admissible storage tempera-
ture
-25 °C to 45 
Power consumption, digital sys-
tem phones
see table "Average power requirements of terminals", page 90 and table
"Maximal power requirements of the system phones on the DSI bus",
page 136
Power consumption, IP system
phones
see System Manual for "Aastra Intelligent Net (AIN) and IP system phones"
Terminals
Height (Type of
mounting)
Width
Depth (Type of
mounting)
Weight
Aastra 5360, Aastra 5360ip,
Aastra 5361, Aastra 5361ip
115 mm (desktop 25 °)
151 mm (desktop 45 °)
199 mm (wall)
262 mm
198 mm (desktop 25 °)
166 mm (desktop 45 °)
90 mm (wall)
approx.
850g
Aastra 5370, Aastra 5370ip
115 mm (desktop 25 °)
151 mm (desktop 45 °)
199 mm (wall)
262 mm
198 mm (desktop 25 °)
166 mm (desktop 45 °)
90 mm (wall)
approx.
875 g
Aastra 5380, Aastra 5380ip
115 mm (desktop 25 °)
151 mm (desktop 45 °)
199 mm (wall)
262 mm
198 mm (desktop 25 °)
166 mm (desktop 45 °)
90 mm (wall)
approx.
935 g
