Installation
94
Aastra 470 ab R3.0
syd-0337/1.5 – R3.0 – 05.2013
4. 2 Fitting the communication server
The Aastra 470 communication server is designed for installation in a 19” rack (2
height units). The communication server can also simply be placed on a flat sur-
face. Wall-mounting is not allowed.
4. 2. 1 Equipment supplied
The equipment supplied with the Aastra 470 includes:
• Aastra 470 communications server with integrated Call Manager card
• Fastening kit for rack mounting
• 2 covers for the rack screws
• 4 rubber feet for desktop installation
• Power cord
• Product information
4. 2. 2 Location requirement
The following location requirements must be observed when positioning the com-
munication server.
Hazard
Failure to observe the location requirements can cause the communica-
tion server to overheat, damaging electrical components and/or the sur-
rounding area.
An event message is generated if the heat dissipation is insufficient.
Appropriate measures must then be taken immediately to improve heat
dissipation, e.g. providing the required clearances or lowering the ambi-
ent temperature.
Tab. 37 Aastra 470 Location requirements
Heat radiation • Do not position in direct sunlight, near radiators or near other heating sources
EMC • Do not position in strong electromagnetic fields of radiation
(e.g. near x-ray equipment, welding equipment or similar).
Heat dissipation • With desktop and rack mounting the ventilation holes (left) and the fan outlet (rear) must
not be obstructed.
• All the communication server’s housing openings must always be closed during opera-
tion to ensure a controlled flow of air (see Fig. 18).
Environment • Ambient temperature 5 °C...45 °C
• Relative humidity 30…80%, non-condensing
