Expansion Stages and System Capacity
63
Aastra 470 ab R3.0
syd-0337/1.5 – R3.0 – 05.2013
3. 3. 3 applications card CPU2
There are two versions of applications card: CPU2 and CPU2-S. Both models differ
in terms of the fitted standard PC with hard disk, whereby the CPU2 has the more
powerful model. The applications card is connected with the call manager call via
Ethernet and the backplane, which means that the Ethernet interface on the front
panel is not required.
The Windows operating system and the Aastra applications Open Interfaces Plat-
form (OIP) and the fax service are preinstalled on the application card’s standard
PC. On the CPU2 applications card, the Aastra Telephony Web Portal (TWP) applica-
tions are additionally pre-installed.
Fig. 16 Interfaces, display and control elements of the applications card
[3]
[2]
[5]
[8]
[7]
[6]
[1]
[4]
