Operation and Maintenance
223
Aastra 470 ab R3.0
syd-0337/1.5 – R3.0 – 05.2013
The call manager card is defective
If a defective call manager card is replaced, the EIM card has to be switched from
the defective call manager card to the new one. For instructions on how to replace
the call manager card, see "To replace a call manager card, proceed as follows:",
page 232.
The EIM card is defective
In the unlikely event of a defective EIM card, contact your authorized dealer to dis-
cuss the procedure.
For the procedure for switching an EIM card see "Replacing the EIM card", page 230.
6. 3. 3 Interface cards
The different card types, the number of slots and the maximum configuration are
all determined by the system capacity (see "3 Expansion Stages and System Capac-
ity").
A number of rules have to be observed when fitting the cards (see "Component
mounting rules", page 113.
All configuration data is centrally stored in non-volatile Flash memory. This means
that configuration data is preserved whenever a defective interface card has to be
replaced by a new one.
6. 3. 3. 1 Replacing a defective interface card
A card is replaced by the same card type with the same number of ports.
Procedure:
Warning
Be sure to observe the "Safety regulations", page 95.
1. Carry out preparations (see "Preparations", page 221).
2. Unscrew the screw on the defective interface card and remove the card by pull-
ing the fastening screw.
3. Carefully slide the new interface card into the slot shaft and gently press the
card as far as it goes into the connection on the backplane.
4. Use the screw to secure the card in its slot.
5. Restart the call manager by pressing the On/Off button on the call manager card.
