Aastra 470 System Manual

Annex
283
Aastra 470 ab R3.0
syd-0337/1.5 – R3.0 – 05.2013
Tab. 126 Electrical data
Tab. 127 Heat dissipation
7. 3. 4 Dimensions of cards and modules
Tab. 128 Dimensions of cards and fan-out panels
Tab. 129 Modules
Internal power supply Aastra
470
Auxiliary power supply unit
(APS2)
Class of protection 1 1
Input voltage 103 V...127 V or 207 V...253 V,
48...62 Hz
100 V…240 V, 48...62 Hz
Input current approx. 0.2 A...2.2 A (115 V)
approx. 0.1 A...1.1 A (230 V)
approx. 0.2 A...4.0 A (115 V)
approx. 0.2 A...2.0 A (230 V)
Resistant to voltage breaks < 20ms < 20ms
Power input with min. configuration approx. 25 W approx. 25 W
Power input with max. configuration approx. 140 W approx. 260 W
Undervoltage limit
(system reset, data backup)
< 90 V < 90 V
Aastra 470
Basic system with auxiliary power supply unit approx. 140 W = 504 kJ/h
Maximally configured system approx. 400 W = 1440 kJ/h
Card Dimensions width x height x depth [mm]
Interface cards 93 x 41 x 265
Call Manager card CPU1 154 x 41 x 265
Application card CPU2 154 x 41 x 265
Fan-out panel FOP 481 x 44 x 69
Card Dimensions length x width [mm]
DSP module 90 x 56
IP Media module 85 x 85
Call charge module 83 x 60
