Aastra 470 System Manual

Operation and Maintenance
225
Aastra 470 ab R3.0
syd-0337/1.5 – R3.0 – 05.2013
6. 3. 3. 3 New card with more ports
A card is replaced by a similar card with more ports.
Procedure:
1. Change the card and put the system into operation again. Similar procedure as
described in "Replacing a defective interface card", page 223.
2. Select Confirm system configuration in the AMS Configuration Manager.
3. Configure new ports.
The system configuration data (User No., User configuration, etc.) of the terminals
on the new ports is created as new data (default values).
Tab. 93 Example: Expanding the number of terminal or network interfaces
6. 3. 3. 4 Change slot
Interface cards can be moved to a different slot. The terminal configuration data of
the system phones can be transferred.
Procedure:
1. Change the slot and put the system into operation again. Similar procedure as
described in "Replacing a defective interface card", page 223.
2. Connect the system phones to the ports of the new slot.
3. Re-configure port allocation using the AMS Configuration Manager.
4. Insert the card in the new slot in AMS and remove it from the old slot. The con-
figuration data at the old slot location is now deleted.
Note:
Not all cards can be equipped on all slots (see "Component mounting
rules", page 113).
8DSI  16DSI The configuration data of terminal interfaces 9...16 is created as new data.
4BRI  8BRI The configuration data of terminal interfaces 5…8 are created as new.
