Aastra 470 - Technical Data; Network Interfaces

Annex
280
Aastra 470 ab R3.0
syd-0337/1.5 – R3.0 – 05.2013
Tab. 122 Overview of spare parts
7. 3 Technical Data
7. 3. 1 Network interfaces
The following technical data applies to the network interfaces:
Basic rate interface BRI-T
• Standard Euro ISDN interface as per CTR-3
• Configurable for point-to-point or point-to-multipoint operation
Analogue network interfaces
• Voice path with A/D and D/A conversion (standard PCM, A-law)
• Transmission as per ES 201 168 (level country-specific)
• Signalling as per TBR 21
• Pulse or DTMF dialling, Flash signal
MOV958.EXP.APS2-1 Auxiliary power suply unit with fastening kit(APS2)
SEV958.EXP.RFU-1 Redundant fan unit on fastening frame (RFU)
KAB958 CABLE RJ45-08-6M-1 Prefabricated system cable 4 x RJ45, 6 m
ELE957 CABLE-RJ45-6M-1 Prefabricated system cable 12 x RJ45, 6 m
CABLE PATCH 8P 1M SHIELDED BLUE RJ45 patch cable, blue, screened, 1 m
CABLE PATCH 8P 2M SHIELDED BLUE RJ45 patch cable, blue, screened, 2 m
1)
Version varies from country to country
2)
The availability/release depends on the sales channel.
3)
Available as of R2.1 SP1
Designation Description
SPARE PART /SEV958 CPU1-1 Call manager card CPU1 (excl. RAM, Flash, EIM)
SPARE PART /SEV958 DRAM-1G-1 RAM module for call manager card CPU1
SPARE PART /SEV958 CF-1G-1 Flash module for call manager card CPU1
SPARE PART /SEV958.EXP.A470-LIC-1 EIM card for call manager card CPU1
SPARE PART /SEV958 FAN-1 Fan with fastening screws
SEV957 PSU-60W-1 Power supply unit for EFOP fan-out-panel
SEV957 MAINS CABLE-1 Two-pin standard Euro power cable for EFOP fan-out-
panel power supply unit
Designation Description
