Aastra 470 System Manual

Annex
279
Aastra 470 ab R3.0
syd-0337/1.5 – R3.0 – 05.2013
7. 2 Equipment Overview
Tab. 121 Equipment Overview
ID 4FXS = analogue terminal card with 4 FXS interfaces
Colour code on terminals Colour designation in accordance with EU directive
Generation and version Example: –3C = 3. Generation, Version C
(Generation new modules: -1)
Notes:
• A generational change is effected following substantial
changes to the functionality of a PCB.
• A change of version is effected following small changes to
functions or once faults have been remedied. Backward com-
patibility is guaranteed.
Designation Description
PBX958.EXP.A470-1 Aastra 470 basic system with CPU1 call manager card
CABLE-MAINS 3X0.75MM2 3-pin network connection cable
1)
MOV958.EXP.CPU2-1 CPU2 applications card
MOV958.EXP.CPU2-2 CPU2-S applications card
MOV957.EXP.SM-DSPX1-1 DSP module SM-DSPX1
MOV957.EXP.SM-DSPX2-1 DSP module SM-DSPX2
EIP1-8 IP Media module EIP1-8
EIP1-32 IP Media module EIP1-32
MOV958.EXP.4TAX-1 4TAX call charge module
2)
MOV958.EXP.8TAX-1 8TAX call charge module
2)
MOV958.EXP.16TAX-1 16TAX call charge module
2)
MOV958.EXP.1PRI-1 1PRI ISDN primary trunk card
MOV958.EXP.2PRI-1 2PRI ISDN primary trunk card
MOV958.EXP.4BRI-1 4BRI ISDN basic trunk card/terminal interface card
MOV958.EXP.8BRI-1 8BRI ISDN basic trunk card/terminal interface card
MOV958.EXP.4FXO-1 4FXO analogue trunk card
2)
MOV958.EXP.8FXO-1 8FXO analogue trunk card
2)
MOV958.EXP.16FXO-1 16FXO analogue trunk card
2)
MOV958.EXP.8DSI-1 Terminal card 8DSI
MOV958.EXP.16DSI-1 Terminal card 16DSI
MOV958.EXP.32DSI-1 Terminal card 32DSI
MOV958.EXP.4FXS-1 Terminal card 4FXS
MOV958.EXP.8FXS-1 Terminal card 8FXS
MOV958.EXP.16FXS-1 Terminal card 16FXS
MOV958.EXP.32FXS-1 Terminal card 32FXS
MOV958.EXP.FOP-1 Fan-out panel FOP
MOV958.EXP.EFOP-1 EFOP fan-out-panel without power supply unit and Euro power
cable
3)
