6. 4. 4 Colour display
The colour display has different display modes, which depend in part on the Call
Manager's operating mode.
The table below summarises the display modes.
Tab. 101 Operating modes and display priorities
Display mode of the colour
display
Call Manager
operating mode
Trigger event and purpose
Error mode
(Error Mode)
System setup 2 • Triggered by software or hardware error.
• The error is shown on the display.
• The system is unable to run.
Boot menu
(Boot command mode)
System setup 2 • Is shown during the start-up phase 2 (LED pattern 5 in
Tab. 97) during approx. 3 seconds.
• Allows the user to reset the IP address data or to carry
out a first start.
Menu mode
(Application command mode)
Normal operation • Triggered by pressing any navigation key briefly in
the traffic load mode.
• Allows the user to run various advanced functions.
Traffic load mode
(Traffic mode)
Normal operation • After the startup of the Call Manager or after exiting
the menu, idle or event message mode.
• Shows the current traffic load of the Call Manager.
Idle mode
(Idle mode)
Normal operation • After a certain amount of time without user interac-
tion from the traffic mode or the event message
mode.
• Screen saver and energy saving function.
Event message mode
(Event message mode)
Normal operation • After one or more event messages are received.
