Aastra 470 System Manual

Installation
136
Aastra 470 ab R3.0
syd-0337/1.5 – R3.0 – 05.2013
Restrictions
The maximum length of an DSI-AD2 bus is further restricted by:
• the maximum power requirements of the connected system phones and their
supplementary equipment. In this context the SB-4+ and SB-8 DECT radio units
are also considered as system phones.
• the line resistance (depending on the line length and wire diameter)
Tab. 58 Maximal power requirements of the system phones on the DSI bus
System phone
1)
1)
Assumptions:
System phones: In hands-free mode, loudspeaker on maximum volume, all LEDs lit
Aastra 5380: Backlighting with maximum brightness
Expansion key modules: All LEDs lit
Radio units: Active call connection on all channels
Connection Max. power input [mW]
Aastra 5360
2)
2)
Although no longer available, the phone is still supported.
DSI-AD2 interface 900
Aastra 5361 DSI-AD2 interface 1220
3)
Aastra 5370 DSI-AD2 interface 1220
3)
3)
The value can increase to approx. 600 mW if the power available at the DSI-AD2 bus allows it.
Aastra 5380 DSI-AD2 interface 1340
3)
Aastra 5370, Aastra 5380 with power supply unit DSI-AD2 interface 0
Expansion key module Aastra M530 Aastra 5370 300
Expansion key module Aastra M530 Aastra 5380 500
Expansion key module Aastra M535 Aastra 5370, Aastra 5380 0
4)
4)
An Aastra M535 always requires a power supply unit
Dialog 4220 DSI-DASL interface 500
Dialog 4222 DSI-DASL interface 660
Dialog 4223 DSI-DASL interface 680
EKP expansion key module Dialog 4222, Dialog 4223 190
DECT radio unit without power supply unit SB-4+ DSI-AD2 interface 1700
5)
DECT radio unit without power supply unit SB-8 2 DSI-AD2 interfaces 1550
6)
DECT radio unit with power supply unit SB-4+/SB-
8
1 or 2 DSI-AD2 interfaces < 100
Office 10
2)
DSI-AD2 interface 900
Office 25
2)
DSI-AD2 interface 900
Office 35
2)
DSI-AD2 interface 630
7)
Office 45
2)
DSI-AD2 interface 1110
7)
Office 45pro with power supply unit
2)
DSI-AD2 interface < 10
Expansion key module (EKP)
2)
Office 35 150
Expansion key module (EKP)
2)
Office 45 210
Alpha keyboard
2)
Office 35, Office 45 30
