Aastra 470 System Manual

Expansion Stages and System Capacity
90
Aastra 470 ab R3.0
syd-0337/1.5 – R3.0 – 05.2013
Tab. 35 Average power requirements of terminals
Tip
With the planning application Aastra Plan the power supply available for
terminals is checked automatically.
Terminals Connection Output P [mW]
Aastra 5360
1)
1)
Although no longer available, the phone is still supported.
DSI-AD2 interface 280
Aastra 5361 DSI-AD2 interface 680
Aastra 5370 DSI-AD2 interface 680
Aastra 5380 DSI-AD2 interface 820
Aastra 5370, Aastra 5380 with power supply
unit
DSI-AD2 interface 0
Expansion key module Aastra M530 Aastra 5370 110
Expansion key module Aastra M530 Aastra 5380 120
Expansion key module Aastra M535 Aastra 5370, Aastra 5380 0
2)
2)
An Aastra M535 always requires a power supply unit
Dialog 4220 DSI-DASL interface 390
Dialog 4222 DSI-DASL interface 640
Dialog 4223 DSI-DASL interface 660
EKP expansion key module Dialog 4222, Dialog 4223 45
Radio unit without power supply unitSB-4+ DSI-AD2 interface 1500
3)
3)
The value applies to radio units with hardware version "-2". The value for hardware version "-1" is 300 mW
lower.
Radio unit without power supply unitSB-8 2 DSI-AD2 interfaces 1350
4)
4)
The value applies to each interface and to radio units with hardware version "-2". The value per interface for
radio units with hardware version "-1" is 150 mW lower.
Radio unit with power supply unit SB-4+/SB-8 1 or 2 DSI-AD2 interfaces < 100
Office 10
1)
DSI-AD2 interface 340
Office 25
1)
DSI-AD2 interface 380
Office 35
1)
DSI-AD2 interface 280
5)
5)
The value applies to phones with hardware version "-2". The value for phones with hardware version "-1" is
60 mW lower.
Office 45/45pro
1)
DSI-AD2 interface 660
5)
Office 45pro with power supply unit
1)
DSI-AD2 interface < 10
Expansion key module (EKP)
1)
Office 35, Office 45 80
Alphanumerical keyboard (AKB)
1)
Office 35, Office 45 20
ISDN terminal BRI-S interface approx. 500
6)
6)
The value depends greatly on the terminal type.
Analogue terminals FXS interface approx. 500
