Aastra 470 System Manual

Installation
117
Aastra 470 ab R3.0
syd-0337/1.5 – R3.0 – 05.2013
Prefabricated system cable 12 x RJ45
The cable is 6 m long and, at one extremity, has 12 RJ45 connectors for the inter-
faces on the front panel. Two of them have 4 cores; the others, 2 cores. This means
the cable is suitable for connecting the following interfaces:
• 2 network interfaces BRI-T or 2 terminal interfaces BRI-S or a combination thereof.
• 10 terminal interfaces (DSI, FXS) or a combination thereof.
Note:
This cable cannot be used to connect Ethernet interfaces (see also "Con-
nection of PRI primary rate interface", page 125 and "Connection of Ether-
net interfaces", page 166).
Tip
Use standard commercial connecting cables not just for the PRI and
Ethernet interfaces but also for connecting the BRI-T interfaces.
Tab. 41 Schematic diagram of prefabricated system cable 12  RJ45
Stranded ele-
ment
Core colour Cable designation
RJ45 Signal
Pin Connection four-wire Two-wire connection
1 white 1 4 f a
blue 5 e b
turquoise 6 d –
violet 3 c –
2 white 2 4 f a
orange 5 e b
turquoise 6 d –
violet 3 c –
3 white 3 4 – a
green 5 – b
turquoise 4 4 – a
violet 5 – b
4 white 5 4 – a
brown 5 – b
turquoise 6. 4 – a
violet 5 – b
5 white 7 4 – a
grey 5 – b
turquoise 8 4 – a
violet 5 – b
