Aastra 470 System Manual

Installation
168
Aastra 470 ab R3.0
syd-0337/1.5 – R3.0 – 05.2013
Status LED
The status of the Ethernet interfaces is indicated by the green and yellow LEDs di-
rectly on the interface in question.
Fig. 70 Status LED on the Ethernet interfaces
Tab. 76 Status LED on the Ethernet interfaces
Cable requirements
Use commercial Cat. 5 cable, or choose a cable type with the following characteris-
tics:
Tab. 77 Requirements for an Ethernet cable
See also:
Informations about the on the Ethernet interface can be found on the
applications card in the Installation Instructions for the CPU2 application
card.
Green LED Yellow LED Rate State
On On 10 Mbit/s Port has a connection with the network
flashing flashing 10 Mbit/s Port is receiving or sending data
On Off 100 Mbit/s Port has a connection with the network
flashing Off 100 Mbit/s Port is receiving or sending data
Off On 1 Gbit/s Port has a connection with the network
Off flashing 1 Gbit/s Port is receiving or sending data
Core pairs  cores 4  2
Stranded yes
Wire diameter, core 0.4...0.6 mm
Screening yes
Category Cat. 5 minimum
8"/

-"/
-"/-"/
