34 XFC G4 2103335 Rev AB
3.7.4 Log Period Records
Each record has entries that contain the following information:
— Average SP (Static Pressure)
— Average DP (Differential pressure)
— Average FT (Flow Temperature)
— Calculated Volume
3.7.4.1 Log Period Data Entries
Log period data entries are made every 60 minutes, by default. The period may be changed to one of six other choices
(1,2,5,10,20,30,60). Choosing a log period of less than 60 minutes will result in additional records being logged. As such, this
requires more storage space to hold a full day’s data. The log period must never be less than the volume calculation period.
3.7.4.2 Volume Calculation Period Entries
Volume calculation period entries are made every 60 minutes, by default. The user may change this period to one of six other
choices (1,2,5,10,20,30,60). The volume calculation period should never be greater than the log period and should be evenly
divisible into the log period.
Volume calculations are completed following the top of the current period (i.e., top of the hour, top of the minute).
3.8 Display Function
During operation of the flow computer, the front panel LCD continuously scrolls through the operating parameters. Table 5
shows the typical displayed parameters; however, any parameter with a register address can be displayed. The duration that the
parameter is displayed can vary from 1 to 255 seconds (default is five seconds); a setting of zero (0) seconds will set any
display to off. See Program Display in Chapter 3 (and PCCU32 help files) for more details.
Table 5 Typical XFC
G4
Display Options
Display
Description
DATE/TIME
MM/DD/YY HH:MM:SS
Current Date and Time
24 hour clock
YEST DP LO
NN PERCENT
Yesterday’s Percent DP Low Limit
Percent time below DP Low Set Point
YEST DP HI
NN PERCENT
Yesterday’s Percent DP High Limit
Percent time below DP High Set Point
FLOWRATE
NNNNNN.N SCF/HR
Current Flow Rate
Programmable SCF or MCF or MMCF
ACCUM VOL
NNNNNN.NN MCF
Total Accumulated Volume
Programmable SCF or MCF or MMCF
BATTERY
NN.N VOLTS
Battery Voltage
Volts
DIFF PRESS
NNN.N IN. H2O
Differential Pressure
Inches H2O
PRESSURE
NNN.N PSIA
Static Pressure Absolute
PSIA
FLOW TEMP
NN.N DEG. F
Flowing Temperature
°F
YEST VOL
NNNN.N MCF
Yesterday’s Volumez
Programmable SCFM or MCF or MMCF
PERIOD VOL
NNNN.N SCF
Previous Period Volume
Last volume calculation period volume
CHARGER
NN.N VOLTS
Charger Voltage
M_FLOWRATE
NNNNNN.N SCF/HR
Minute Average Flow Rate
