ABB XFCG4 6413 - Figure 46 Model XFC 6413 Direct Mounted, Instrument Manifold; G4 6413 Direct Mounted, Instrument Manifold; Figure 47 Model XFC 6713 Direct Mounted; G4 6713 Direct Mounted

64 XFC G4 2103335 Rev AB
Figure 46 Model XFC
G4
6413 Direct Mounted, Instrument Manifold
Figure 47 Model XFC
G4
6713 Direct Mounted
INSTRUMENT
MANIFOLD
5 VALVE
ORIFICE
MEASUREMENT & CONTROL SYSTEMS
G4
XFC
15.10"
13.25"
18.80"
28.55"
