92 XFC G4 2103335 Rev AB
5.5.1 Station ID
The station identifier code should uniquely identify one station from that of others. If running a multiple tube station, the station
ID is the same for all tubes on that flow computer. If left blank on a single tube device, it will be the same as the device ID.
5.5.2 Device ID/Application ID
The device identifier should uniquely identify each tube/application on a multi-tube device. On a single tube installation, the
identifier code should uniquely identify one XFC
G4
from that of others and will be the same as the Station ID.
5.5.3 Location
In WINCCU, the host software, the location field can hold up to 24 alphanumeric characters to describe its location. An example
would be the county name or road number.
There are additional fields stored in WINCCU for uniquely identifying the meter including fields for entering the
lease holder, producer, operator and buyer. These fields reside on the host computer in the ID Manager, not in
the flow computer.
5.5.4 Date/Time
The flow computer date and time must be set correctly and should agree with the Collection Equipment.
5.5.5 Bi-Level Security System
Data and configuration security in the XSeries meters (XFC, XRC and uFlo) is spread across three elements; the flow meter,
PCCU32 and WinCCU32.
The flow meters (XFC, XRC or uFlo) have a security switch (S1) on the electronic boards. Password security is bi-level; read
only (security code level 1) or read/write (security code level 2). To establish meter security the security switch must be in the
OFF position, and locally connect with PCCU32.
5.5.5.1 Meter Security
To set meter security:
To establish meter security, the security switch must be in the OFF position and locally connected with PCCU32.
Open the door to the flow computer.
Ensure the security switch is in the OFF position.
Connect the PC running PCCU32 to the flow computer with either an MMI cable (RS-232), a USB cable or an
Ethernet cable.
Open PCCU.
