4Installation
Hardware Installation
2D-LC User Guide 88
Activate the 2D-LC System Driver With a Dongle-Based License
When you purchase Agilent 1290 Infinity II 2D-LC Solution from Agilent you will
receive a single USB stick which includes the 2D-LC dongle license. To run the
system and use its functionality, the
2
D pump must be activated. For this
purpose, the physical device is connected to the USB-port on the back of the
2D-LC pump. This will activate and enable the software to use the Agilent 1290
Infinity II 2D-LC Solution in your CDS.
Activate Agilent 1290 Infinity II 2D-LC Solution
1 Power off the module.
2 Plug the USB Dongle into the 1290 Infinity I or II binary pump USB Socket on
the back of the module.
3 Power on the module.
4 Once restarted, the 2D-LC License is activated and you can remove the USB
Dongle and store in a safe place.
Deactivate the License (Deactivation Steps in LabAdvisor)
For the deactivation of the license on the 2D-LC pump (e.g. you want to use the
license on a different 2D-LC pump) you have to use the LabAdvisor Diagnostic
Software.
1 Insert the USB Dongle at the rear of the
2
D pump.
2 Deactivate the license under Instrument Control > Pump > Special Commands >
License Dongles.
3 Remove the USB dongle at the rear of the pump and keep it on a safe place.
For further information, see “Agilent Lab Advisor Software” on page 278.
Parts required Description
USB Dongle
The dongle is required for a re-activation of 2D-LC License after mainboard
replacement.
When the 2D-LC Driver connects to the instrument, it checks if a license is
available. If no licence is available, the driver remains offline. Tooltip when
hovering over the 2D-LC UI in the dashboard of the CDS shows the text: No 2D-LC
license available.
