2D-LC User Guide 55
4Installation
Hardware Installation
The Capillary Kit 2D-LC, 1290 Infinity II contains the following parts:
Options
# p/n Description
2 5043-0269 Adapter-profile
for Agilent 1290 Valve Drive (G1170A)
1 5067-4608 Capillary ST 0.17 mm x 280 mm SX/S
2 5067-4651 Capillary ST 0.12 mm x 280 mm SL/SX
1 5067-4669 Capillary ST 0.12 mm x 600 mm S/SL
1 5067-4670 Capillary ST 0.17 mm ID 600 mm pre-swaged
1 5500-1217 Capillary, ST, 0.17 mm x 900 mm SI/SX
1 5500-1227 Capillary ST 0.17 mm x 150 mm SL-SL
1 5500-1240 Capillary ST 0.17 mm x 105 mm SL/SL
2 5500-1245 Capillary ST 0.17 mm x 400 mm SI/SI
2 5500-1251 Capillary ST 0.12 mmX 400 mm SL/SL
Depending on the set up of you instrument, extra parts and capillaries might be
required for instrument set up. Those parts are ordered separately or are shipped
with other components, for example the 2D-LC or MHC valves. Their origin as
well as their function is described in the instrument setup section below.
The Agilent 1290 Infinity II 2D-LC Solution must contain an Agilent Infinity II
High-Speed Pump G7120A, Agilent Infinity II Bio High-Speed Pump G7132A, or
Agilent 1290 Infinity Binary Pump G4220A as
2
D pump.
This is necessary to achieve the following:
• Synchronize valve switches
• Run fast gradients on the
2
D column
