13 Parts for Maintenance
Vale Options Overview (for 2D-LC)
2D-LC User Guide 344
Vale Options Overview (for 2D-LC)
The 1300 bar InfinitLab Quick Change Valves are backward compatible to the
1200 bar Valves.
G4136A 2D-LC Valve Kit, Standard
5067-4244 2D-LC Valve Head, 1300 bar
The service life of a stator depends on the stress to which the 2D-LC valve is
subjected. Therefore, a visual inspection of the surface during maintenance is
very important. If scratches or heavy wear is visible during the inspection, the
stator must be replaced.
# p/n Description
1 5067-4244 2D-LC Valve Head, 1300 bar
1 5067-5440 Calibrated loop kit for 2D-LC
1 5067-6171 Capillary Kit 2D-LC, Infinity Classic (optional)
Internal part, not orderable
1 G4236-68000 2D-LC Easy Starter Kit
Internal part, not orderable
2 G4242-64000 Multiple Heart-Cutting Valve
1 5067-6585 Capillary Kit 2D-LC, 1290 Infinity II
Internal part, not orderable
1 G1680-63721 Network LAN Switch
# p/n Description
3 1535-4857 Stator screws, 10/pk
1 1535-4045 Bearing ring
1 5068-0214 Rotor Seal (VHP)
1 5068-0120 Stator ring
1 5068-0115 Stator
