2D-LC User Guide 343
13 Parts for Maintenance
Valve Head Parts
Technical specifications
Tools
Tool for extra fittings
Table 38 Technical specifications
Max. Pressure: 1300 bar
Liquid Contacts: Stainless Steel, PEEK
Connections: Accepts 10-32 male threaded and M4 fittings
p/n Description
8710-2462 Hex Key Driver 3/32 inch
5023-2504 Hex driver SW-4 slitted
For M4 fittings
5067-6141 M4 Blank nut
For plugging unused valve ports
5067-6127 Blank Nut SL
