11 Error Information

General Error Messages

2D-LC User Guide 310

Leak Sensor Short

Error ID: 0082

The leak sensor in the module has failed (short circuit).

The current through the leak sensor is dependent on temperature. A leak is

detected when solvent cools the leak sensor, causing the leak sensor current to

change within defined limits. If the current increases above the upper limit, the

error message is generated.

Leak Sensor Open

Error ID: 0083

The leak sensor in the module has failed (open circuit).

The current through the leak sensor is dependent on temperature. A leak is

detected when solvent cools the leak sensor, causing the leak sensor current to

change within defined limits. If the current falls outside the lower limit, the error

message is generated.

Probable cause Suggested actions

1 Defective leak sensor.
