12 Maintenance
Replacing the Fuses of the Infinity Valve Drive
2D-LC User Guide 332
Replacing the Fuses of the Infinity Valve Drive
When
If the flow module shows no reaction.
Tools required Description
Screwdriver
Parts required # p/n Description
2 2110-1486 Fuse 2 AT250 V
Electrical shock
 Disconnect the module from line power before changing a fuse or trying
to open the hatch of the power input socket.
 Never reconnect the line power before havingthe power input socket
closed.
1 Switch off the instrument. The line switch is located at
the rear of the module.
2 Disconnect the power cable from the power input
socket.
