Agilent Technologies 1290 Infinity II 2D-LC User Manual

2D-LC User Guide 341
13 Parts for Maintenance
Valve Driver Parts Infinity II
Valve Driver Parts Infinity II
Figure 165 Parts for 1260/1290 Infinity II Valve Drive
Item p/n Description
1 5067-6138 Valve Holder Kit Right-IF-II-G
For G7116A/B
5067-6139 Valve Holder Kit Left-IF-II-G
For G7116A/B (Not shown)
2 5067-5685 Clamp Guide Kit-IF-II
3 5067-4792 Leak sensor assembly
External leak plane
4 5043-0271 Holder leak plane
5 5043-0270 Leak plane
6 2110-1486 Fuse 2 AT250 V
7 5063-6527 Tubing, Silicon Rubber, 1.2 m, ID/OD 6/9 mm
8 5181-1519 CAN cable, Agilent module to module, 1 m
9 5500-1156 T-Tube Connector ID6.4
10 5043-0269 Adapter-profile
For G1170A (Multiple valve drives can be connnected with adapter profiles)
1
2
3
4
5
6
7
8
9
10
