2D-LC User Guide 349
13 Parts for Maintenance
MS Diverter Valve
Alternative diverter valves (2-position/6-port, Vespel Rotor Seal)
Alternative diverter valves (2-position/10-port, Vespel Rotor Seal)
Additional Parts for the MS Diverter Valve Setup
p/n Description
5067-4117 2-position/6-port ultra high pressure valve head, 1200 bar
5068-0008 Rotor Seal (Vespel)
p/n Description
5067-4118 2-position/10-port ultra high pressure valve head, 1200 bar
5068-0012 Rotor Seal (Vespel)
p/n Description
G4212-60022 Pressure Relief Valve
5067-4606 Capillary ST 0.12 mm x 400 mm SX/-
0890-1915 Capillary PK 0.13 mm x 150 cm
5500-1228 Capillary ST 0.3 mm x 80 mm SL-SL
5063-6591 PEEK Fittings 10/PK
0100-0969 TEE, ST, 1/16 inch, Low Dead Volume
5067-6127 Blank Nut SL
5062-2462 Tube PTFE 0.7 mm x 5 m, 1.6 mm od
